上海维宏电子科技股份有限公司
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD
7 / 52
1.2.1.3 Mode Buttons
They are used to switch among the following modes:
• : in this mode, the machine tool will automatically run the program
file.
• : in this mode, it is convenient to return to the machine origin or set
datum.
• : in this mode, the machine tool will keep running until you release the
button.
• : in this mode, the machine tool will be controlled by handwheel.
• : in this mode, the machine tool only will move 0.001(mm), 0.01(mm),
0.1(mm) or a customized step size.
The last three modes are referred as Manual mode.
1.2.1.4 E-stop Button
It is used to stop the machine tool completely when it is in danger by triggering the
emergency alarm.
When the danger is cleared, you can remove the alarm by rotating the button in the
clockwise direction.
1.2.1.5 Auxiliary Function Buttons
They are used to turn on or off the following frequently used ports:
• : used to turn on/off blowing.
