WEIHONG 200 Series User Manual

上海维宏电子科技股份有限公司
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD
8 / 52
• : used to turn on/off the lubricant.
• : used to turn on/off the light.
• : used to turn on/off the coolant.
• : not customized yet.
• ~ : used to customize function.
1.2.1.6 Override Switches
They include the following switches:
• : used to adjust the spindle override form 50% ~ 150%.
• : used to adjust the feed override from 0% ~ 120%.
1.2.1.7 Movement Control Buttons
They are used to control the movement of the machine tool:
• / : used to start / stop the rotation of the spindle.
• / / : used to control machining.
See Execute machining for details.
