WEIHONG NK200 User Manual

Specialized Concentrated Focused
「82」Operation
CAUTION
Since mechanical configuration of tool magazine varies, the process mentioned above is just applied to the general
situation. In case of any difference, please turn to manufacturer to make corresponding adjustment based on actual
situation.
3.17.3 Tool Change Parameters
Parameter
Definition
Setting Range
X-axis change tool
range upper limit
X-axis machine coordinate of table travel
upper limit in tool change
Change tool range lower
limit~67108.864
Y-axis change tool
range upper limit
Y-axis machine coordinate of table travel
upper limit in tool change
Z-axis change tool
range upper limit
Z-axis machine coordinate of table travel
upper limit in tool change
X-axis change tool
range lower limit
X-axis machine coordinate of table travel
lower limit in tool change
-67108.864~ change tool range
upper limit
Y-axis change tool
range lower limit
Y-axis machine coordinate of table travel
lower limit in tool change
Z-axis change tool
range lower limit
Z-axis machine coordinate of table travel
lower limit in tool change
Tool magazine
capacity
The maximum tool quantity saved in tool
magazine. After tool capacity is modified,
please reboot system before setting
corresponding tool coordinates
1~20
Current tool no.
The tool number of the tool currently used
1~tool magazine capacity
Currently tool pan
no.
The tool number of the tool dispaly in
magazine
1~tool magazine capacity
Tool change
prompt
Whether to pause and prompt in case of
tool change command
False :Invalid
True: Valid
Calibrate cutter
after tool change
Whether to preset automatically after tool
change
False :Invalid
True: Valid
T0 handle mode
0: invalid; 1: to be no-tool state; 2: first tool
index is 0
0; 1; 2
Tool change upper
position
Z machine coordinate of tool change
upper position
-
Tool change lower
position
Z machine coordinate of tool change
lower position
-
X change tool
position
X-axis machine coordinate of spindle in
tool change, generally used in disk
magazine parameter settings
-
