WM 68331 04/2021
LIFE-BASE EN 41
4 Assembly
1. Open the latches on the cylinder brackets (1).
2. Unhook the retaining bolt (2).
3. Insert the oxygen cylinder from the side into the portable unit.
4. Notice! Damage to cylinder brackets!
Turn the retaining bolt to adapt the tensioning force of
the cylinder brackets precisely to the oxygen cylinder.
