Weinmann LIFE-BASE Series User Manual

44 EN LIFE-BASE
WM 68331 04/2021
4 Assembly
4. Use 4 screws 100 and 4 protective disks 104 to screw
the device to the portable unit.
5. Connect the device to the power supply according to
the instructions for use.
6. Complete attachment of the device to the portable unit
(see "4.5.7 Completing assembly", page 80).
Result The device is attached to the portable unit.
4.5.2 Attaching the device to LIFE-BASE light and
LIFE-BASE III
Applies to • MEDUMAT Standard
a
• MEDUMAT Easy
CPR
• MODUL
100
104
10 mm
MEDUVENT Standard
