WM 68331 04/2021
LIFE-BASE EN 45
4 Assembly
The attachment of MEDUMAT Transport to LIFE-BASE light is
described in a separate section (see "4.5.4 Attaching the device to
LIFE-BASE 1 NG and LIFE-BASE 4 NG (with protective hoops)",
page 51).
Required auxiliary
equipment
Screwdriver with crosshead PH1
1. If available: Fasten the shoulder strap to the portable unit
(see "4.3 Attaching the belt to the portable unit", page 36).
2. Position the device with the control panel membrane facing
downwards.
3. Determine the holes for the device on the portable unit.
4. Place the portable unit on the device.
When doing so, note:
• MEDUMAT Easy
CPR
can be attached in 2 positions to
the portable unit.
• MEDUMAT Easy
CPR
can be attached individually or
together with MODUL to the portable unit.
• The holes for the device and the portable unit must be
aligned on top of each other.
MEDUMAT Easy
CPR
or MODUL
LIFE-BASE lightLIFE-BASE light
