Weinmann LIFE-BASE Series User Manual

WM 68331 04/2021
LIFE-BASE EN 51
4 Assembly
9. Use 4 screws 102 to screw the spacer plate to the portable
unit.
When doing so, note: The holes for the portable unit and
the spacer plate must be aligned on top of each other.
10. Complete attachment of the device to the portable unit
(see "4.5.7 Completing assembly", page 80).
Result The device is attached to the portable unit.
4.5.4 Attaching the device to LIFE-BASE 1 NG and
LIFE-BASE 4 NG (with protective hoops)
Applies to MEDUMAT Transport
Required auxiliary
equipment
Screwdriver with crosshead PH1
1. Place the portable unit on a flat, firm surface.
2. If available: Fasten the shoulder strap to the portable unit
(see "4.3 Attaching the belt to the portable unit", page 36).
102
16 mm
MEDUMAT Standard
2
