3 Description
3.5.4 Disposable breathing circuit with reduced dead
space
3-8 Disposable breathing circuit with reduced dead space
4 Check valve diaphragm
Due to the check valve diaphragm, the respiratory
gas only flows towards the patient. No rebreathing
takes place.
5 Holder for check valve diaphragm
Connects the patient valve to the ventilation hose
and contains the check valve diaphragm.
