WM 68071 05/2021
MEDUMAT Standard
2
EN 61
4 Preparation and operation
4. With the reusable breathing circuit: Guide the connection line
with measuring circuit and ventilation hose into the protective
sleeve of the breathing circuit.
5. If necessary: Activate MEDUtrigger option
(see "6.3.9 Options", page 138).
Result MEDUtrigger is connected to the device and is ready for use.
4.4.6 Connecting the inhalation adapter
1. Connect the inhalation adapter to the connection for
ventilation hose on the device.
2. Connect the inhalation mask to the inhalation adapter
or
Connect the tube to the inhalation adapter
or
Connect the nasal cannula to the inhalation adapter.
