CALIBRATION PARAMETERS
Scale Calibration Sub-block 1.x
Parameter Value Description
P1.0
Graduations
1d <
2d
5d
10d
20d
50d
100d
Select scale graduations (d).
Setting this parameter to higher than 10d will set the
decimal point to 0, and display 2 leading zeros at ZERO
(00).
Setting to 100D will result in 3 zeros at ZERO (000).
P1.1
Decimals
0 <
0.0
0.00
0.000
00.0000
Select decimal places (Up to 3).
4 decimal places are used when calibrating in kilograms for
use in grams.
P1.2
Deadload Scale
E SCL
Displays “E SCL” to empty scale. Once the scale is empty,
press ENTER to calibrate deadload value (Scale zero
calibration).
P1.3
Calibrate Scale
SPAn
005000 <
Displays “SPAn”. Place test weight on the scale. Enter the
test weight value using the ARROW keys. Press ENTER to
start calibration.
P1.4
Scale Capacity
005000 <
0 to 999999
Enter the Scale Capacity using ARROW keys. Press
ENTER to select.
P1.5
Overload
0d <
1d
2d
2PC (2%)
Selects the number of divisions over scale capacity where
the display blanks for a scale over (overload) condition.
Choose between 0, 1, 2 divisions or 2% of capacity.
P1.6
Calibrated Units
(Primary Units)
1 = kg <
2 = lb
Selects the Primary scale units used for calibrating the
scale.
Setting this parameter affects P1.7 and P1.8 automatically.
P1.7
Power ON Units
1 = kg <
2 = lb
3 = oz
4 = g
Selects the default units that the scale powers up to.
P1.8
Alternate Units 1
0 = Disabled
1 = kg
2 = lb <
3 = oz
4 = g
Selects alternate unit of measurement 1. Setting to 0
disables alternate unit of measurement 1.
P1.9
Alternate Units 2
0 = Disabled <
1 = kg
2 = lb
3 = oz
4 = g
Selects alternate unit of measurement 2. Setting to 0
disables alternate unit of measurement 2.
Factory default values are bold <.
