Western Scale M1 - Serial Communications Sub-Block 5.X (Continued)

21
Indicator Technical Manua
l
Serial Communications Sub-block 5.x (Continued)
Parameter Value Description
P5.3
Data String
Emulation
COM1
0 = Western DF1500 <
1 = Toledo
2 = Toledo w/ checksum
3 = Toledo w/ checksum
& leading zeros
4 = RiceLake / Condec
5 = Transcell
6 = Cardinal SB400
7 = Cardinal SB200
8 = SMA
9 = A&D 4323
10 = Ohaus CW11
11 = Fairbanks R2500
12 = Weightronix WI125
13 = Transmit value in
====ACC5
Data String emulations for COM1:
Western DF1500 format (19 characters):
<STX>PWWWWWWWUU_MM_S<CR><LF>
<STX> = Start of Text character (ASCII 02)
P = Polarity: ‘-‘ for negative, space for positive.
W = Weight: 7 characters incl. decimal.
UU = Units: ‘KG’, ‘LB’, ‘OZ’, ‘ G’
_ = Space (ASCII 32)
MM = Mode: “GR” or “NT”
S = Status: ‘M’ for motion, ‘O’ for scale over, or
===’space’ for valid
<CR> = Carriage Return (ASCII 13)
<LF> = Line Feed (ASCII 10)
P5.4
Stream Delay
COM1 & COM2
0 = No delay
1 = 0.25 sec <
2 = 0.5 sec
3 = 0.75 sec
4 = 1 sec
Inserts a delay between serial transmissions (select
0.25 second intervals). 0 = No delay.
This parameter affects both COM1 and COM2.
P5.5
Auto Print
Threshold
000000 <
Example:
000000 = No Auto Print
000010 = Auto Prints >= 10
Enter the minimum weight that must be exceeded
before the Auto Print function activates. The weight
must fall below this threshold before another Auto
Print will be performed. Use the ARROW keys to
edit the value, followed by the ENTER key.
P5.6
Baud Rate
COM2
1200
2400
4800
9600 <
19200
Transmission speed (baud rate) for COM2.
P5.7
Data Format
COM2
8 <
7-E
7-O
Data bits and Parity for COM2.
8 = 8 Data bits, No parity
7-E = 7 Data bits, Even parity
7-O = 7 Data bits, Odd parity
P5.8
Output Mode
COM2
0 <
Value 0 - 9
Controls the operation of the COM2 port:
Same values as Parameter 5.2 (Page 20).
P5.9
Data String
Emulation
COM2
0 <
Value 0 - 13
Data String emulations for COM2:
Same values as Parameter 5.3 (Page 20).
Factory default values are bold <.
