Western Scale M1 - Scale Diagnostics Sub-block 9.x

24
Indicator Technical Manua
l
Scale Diagnostics Sub-block 9.x
Parameter Value Description
P9.0
AD Raw Counts
‘A’XXXXX
Show AD converter raw counts for diagnostic
purposes. The left most display will have a blinking “A”
to indicate raw counts mode. Press ENTER to exit.
P9.1
SPAN Edit
XXXXXX
Displays the scale’s calibration factor. Use the
ARROW keys to edit the value, followed by the
ENTER key.
P9.2
Display Test
N/A
Cycles through the display segments of the display.
Press any key to exit.
P9.3
Password
Display/Edit
-0001-
Display/change the calibration PASSWORD.
P9.4
Factory Reset
Reset all parameters back to factory values.
Calibration password is required.
P9.5
Time & Date
0 <
1
2
3
Sets the time & date display format
0 = 12 hour clock, International date (DD/MM/YY)
1 = 12 hour clock, US date (MM/DD/YY)
2 = 24 hour clock, International date (DD/MM/YY)
3 = 24 hour clock, US date (MM/DD/YY)
P9.6
Transmit
Calibration Data
N/A
Transmits Calibration & Ticket data out COM1.
Capture this data as a text file in HyperTerminal, or
upload it directly to another M1 indicator.
The indicator will read “rEAdY”. Press ENTER to
begin or any other key to abort. The display will show
the upload byte count as it is transmitting. The
message “dOnE” will be displayed when complete.
P9.7
Receive
Calibration Data
N/A
Receives Calibration & Ticket data in COM1.
Send this data as a text file in HyperTerminal, or
download it directly from another M1 indicator.
The indicator will read “rEAdY” and wait to receive.
Press any key to abort. The display will show the
download byte count as it is receiving. The message
“dOnE” will be displayed when complete. Exit Cal
Mode and re-start the indicator.
Factory default values are bold <.
