Western Scale M1 - Scale Filtering Settings Sub-block 4.x

19
Indicator Technical Manua
l
Scale Filtering Settings Sub-block 4.x
Parameter Value Description
P4.0
Filter Preset
1 = Light
2 = Medium <
3 = Heavy
4 = Animal
Adjusts filter parameters P4.1 to P4.4 to a preset value.
Use this to quickly find a starting point for scale filtering. If
required, fine tune the filtering by adjusting P4.1 to P4.4
individually.
P4.1
Filter
Frequency
0.5 (Hz)
1 (Hz)
2 (Hz) <
3 (Hz)
Frequency in Hertz of the front end digital filter. A lower
frequency will make the scale more immune to vibrations,
but will also slow down the response time of the display.
P4.2
A/D Averaging
10
50 <
75
100
150
200
Selects the number of A/D conversions that are averaged
to obtain a displayed reading. A higher number gives a
more accurate display by reducing noisy readings, but
slows down the settling rate of the display.
P4.3
A/D Averaging
Cut-Out
Threshold
2d <
4d
8d
12d
14d
18d
Sets the weight change threshold in displayed divisions
where the A/D averaging is suspended. This will make the
display more responsive to weight changes above the cut-
out threshold.
P4.4
A/D Averaging
Cut-Out
Sensitivity
2 <
5
8
10
12
15
Specifies the number of consecutive A/D samples above
the Cut-Out Threshold before A/D Averaging is suspended.
P4.5
Display Update
Rate
0
1 <
2
3
4
Configures how often the display is updated (in 0.25
second intervals). If set to 0 the display updates at full
speed.
Factory default values are bold <.
