Western Scale M1 - Zero and Motion Settings Sub-block 2.x

17
Indicator Technical Manua
l
Zero and Motion Settings Sub-block 2.x
Factory default values are bold <.
Parameter Value Description
P2.0
Pushbutton Zero
Range
2PC (2%) <
10PC (10%)
90PC (90%)
Selects the range (from zero to capacity) within which the
scale can be zeroed. LFT must be 2%.
Example: Scale can be zeroed within ± 2% of calibrated
zero.
P2.1
AZSM Zero
Tracking
OFF
0.5d <
1d
2d
3d
Selects the zero tracking range specified in +/- displayed
divisions. Example: Automatically zeros the scale within ±
0.5d of calibrated zero.
Must be within the Zero Range.
P2.2
Power Up ZERO
IZSM
0 = Disabled <
1 = Enabled
When enabled, the scale will automatically zero on power
up (Up to 2% of scale capacity).
P2.3
Scale Motion
OFF
1d
2d <
3d
5d
10d
Selects the Scale Motion band in displayed divisions.
Determines the number of divisions at which the scale is
sensitive to motion (Motion annunciator turns ON).
P2.4
Motion Timer
4 <
Range: 1 - 20
Selects the time (in 0.25 second intervals) the Motion
annunciator will remain ON after the scale weight stabilizes
within tolerance. Example: For a motion time of 1 second,
set this value to 4.
P2.5
Blank Display on
Motion
0 = Disabled <
1 = Enabled
When enabled, the display blanks when motion is detected.
