Indicator Technical Manua
INTRODUCTION
Best suited to bench and floor scales, the M1 is a basic, 5 button indicator that
features the same high resolution and speed found in other Western instruments.
A compact stainless steel enclosure and large display make the M1 perfect for
virtually all light industrial weighing applications while advanced features like time
& date and programmable tickets ensure the M1 will continue to meet customer
requirements into the future.
Western’s continued dedication to durability, functionality, and versatility make
the M1 engineered for the diversity of the weighing industry.
The following User information is for the exclusive use of WESTERN Dealers and
Customers.
Safety
Installation, configuration, and servicing are only to be done by qualified Scale
Service Technicians as authorized by Western.
Power must be disconnected before servicing the unit. Disconnection from the
line voltage is done by disconnecting the mains plug.
This equipment must be connected to a socket-outlet with a protective earthing
connection. The socket outlet shall be installed near the equipment, and shall be
easily accessible.
This equipment is intended for connection to multiple RATED VOLTAGES or
FREQUENCIES. The switchover to the corresponding voltage is done
automatically by the equipment.
Scale Service Technicians handling M1 PCBs must observe
proper electrostatic discharge (ESD) handling procedures.
ATTENTION! Unauthorized installation and service of this unit
may void the warranty.
CAUTION! HIGH VOLTAGES are present inside the M1
indicator enclosure.
