WIKA operating instructions process transmitter, model UPT-2x
14111166.02 04/2015 EN/DE
EN
5. Commissioning, operation
5.2.6 Connection
1. Pass the connection cable through the cable gland and connect it.
Ensure that no moisture can enter at the cable end.
→ For pin assignment see chapter 5.2.7 “pin assignments”.
2. Tighten the cable gland.
■
Recommended tightening torque 1.5 Nm
■
Check that the seals are correctly seated in order to guarantee the ingress
protection.
3. Perform a mounting correction.
→ Without display, see chapter 7.1 “Performing a mounting correction (oset)”
→ Via HART
®
, see chapter 7.2 “Conguring the HART
®
interface”
→ With display, see chapter 8.5 “Mounting correction (oset)”
4. Attach the push-on cap or display and operating unit and screw the case head cover
tight down to the stop.
