8. Conguration via display and operating unit
8.1.3 Conguring the volume measurement
Requirement
■
Length unit for the lling height is known
■
Medium density is known
■
Characteristic curve of the tank is known (→ see chapter 8.1.4
“Characteristic curves”)
1. Open the operating menu with [↵].
Select “Basic setting” and conrm with [↵].
2. Select “Application” and conrm with [↵].
3. Select “Level” and conrm with [↵].
4. Select “Unit” and conrm with [↵].
5. Select length unit and conrm with [↵].
» Length unit is set.
6. Select “Density” and conrm with [↵].
7. Select “Density unit” and conrm with [↵].
8. Select density unit and conrm with [↵].
» Density unit is set.
9. Select “Density value” and conrm with [↵].
10. Setting the density of the medium.
Set digits using [▲] [▼] and conrm with [↵].
» The cursor moves to the next digit.
» Repeat for each digit.
» Density value is set.
11. Go back two menu levels using [ESC].
Select “Volume” and conrm with [↵].
12. Select “Scale in” and conrm with [↵].
