WIKA operating instructions process transmitter, model UPT-2x
14111166.02 04/2015 EN/DE
EN
8. Conguration via display and operating unit
8.3 Scaling the measuring range
8.3.1 Performing a wet adjustment
For the start of the measuring range and end of the measuring range, the values will be
taken from the running measurement. The respective output signal can be adjusted.
Requirement Measurement is running.
Setting range Start of measuring range: -10 ... +110 % of measuring range
End of measuring range: 1 ... 120 % of measuring range
Max. turndown: 100 : 1 (recommended max. 20 : 1)
1. Open the operating menu with [↵].
Select “Basic setting” and conrm with [↵].
2. Select “Scale setting” and conrm with [↵].
3. Select “Wet adjustm.” and conrm with [↵].
4. Dening the current measured value as start of measuring
range or end of measuring range:
To dene as start of measuring range:
Conrm “min. adjustm.” with [↵].
To dene as end of measuring range:
Conrm “max. adjustm.” with [↵].
5. Change digit using [▲] [▼] and conrm with [↵]. The cursor
moves to the next digit. Repeat for each digit. When the last
digit is exited, the menu moves back to step 2.
With the input of current values that are not
either 4 mA or 20 mA the pressure value is
converted into the standardised current signals
as soon as the current value entered is accepted.
