WIKA operating instructions process transmitter, model UPT-2x
14111166.02 04/2015 EN/DE
EN
11. Instrument information
11. Instrument information
11.1 Display measuring range
1. Open the operating menu with [↵].
Select “Info” and conrm with [↵].
2. Select “Measuring range” and conrm with [↵].
» Measuring range is displayed.
11.2 Display settings
1. Open the operating menu with [↵].
Select “Info” and conrm with [↵].
2. Select “Setting” and conrm with [↵].
» Mode is displayed.
» Scaling is displayed (4 mA und 20 mA).
11.3 Display date of manufacture
1. Open the operating menu with [↵].
Select “Info” and conrm with [↵].
2. Select “Date manufac.” and conrm with [↵].
» Date of manufacture is displayed.
11.4 Display rmware version
1. Open the operating menu with [↵].
Select “Info” and conrm with [↵].
2. Select “Version” and conrm with [↵].
» Firmware version is displayed.
