WIKA operating instructions process transmitter, model UPT-2x
14111166.02 04/2015 EN/DE
EN
6. Display and operating unit, model DI-PT-U
6.4 Setting the main display
The main display can indicate the following values:
■
Pressure Applied pressure is displayed.
■
Level Level is displayed.
■
Volume Volume is displayed.
■
Current Output signal is displayed.
■
PV percent Output signal is displayed as a percentage.
■
Sensor temperature Temperature at the sensor is displayed.
■
PV (primary value) The value corresponding to the mode will be displayed.
If the mode is changed, then the main display will change.
1. Open the operating menu with [↵].
Select “Display” and conrm with [↵].
2. Select “Main display” and conrm with [↵].
3. Select value and conrm with [↵].
» Main display indicates the selected value.
