Installation and operating instructions Wilo-Control EC-Drain PD1 15
5Product information
5.1 Type key
5.3 Scope of delivery
•
Switchgear EC-Drain PD1
(with integrated buzzer)
•Enclosures
• 2 pcs. reducer seals for threaded cable
connection
• 2 pcs. preassembled jumpers
• Installation and operating instructions
5.4 Accessories
Accessories must be ordered separately:
• Immersion bell with 10 m plastic hose and bracket
•Float switch
• Ex-rated cut-off relay for float switches for use in
potentially explosive areas
• Rechargeable battery (NiMH) 9 V / 200 mAh
• Horn 230 V / 50 Hz
• Flash light 230 V / 50 Hz
• Signal lamp 230 V / 50 Hz
See the catalogue for a detailed list
6 Description and function
6.1 Product description (fig. 1)
The EC-Drain PD1 is an electronic switchgear with
an integrated microcontroller.
It controls a pump depending on the switching
status of the connected measurement system.
The switchgear can measure the fluid levels by
means of the different measurement systems.
• Level OFF (A): If the level falls below the level set
as Level OFF, the switchgear switches the pump
off after the configured follow-up time has
passed.
• Level ON (B): If the level rises above the level set as
Level ON, the switchgear switches the pump on.
• High water level (C): If the level rises above the
level set as the high water level, the switchgear
triggers the high water alarm. There is an optical
and acoustic signal, as well as a forced switch-on
of the pump. The collective fault signal is active.
An optional rechargeable battery (accessory)
allows for a mains-independent alarm signal,
which signalises the missing mains voltage by
means of a continuous acoustic signal.
Pump faults are registered and evaluated.
The display of the operating states is signalised by
LEDs on the front side. Operation is done via but-
tons on the right side on the housing.
Example: EC-Drain PD1 (1~)
EC Economy-Controller
Drain Wastewater / sewage
PD1 Pressure drainage for 1 pump
(1~) (1~) = 1~230 V (L, N, PE)
(2~) = 3~400 V (L1, L2, L3, PE)
5.2 Technical data
Mains supply voltage [V]: 1~230 V (L, N, PE)
3~400 V (L1, L2, L3, PE)
Frequency [Hz]: 50/60 Hz
Control voltage [V]:
400 V AC / 230 V AC (dependent on mains supply voltage)
Power consumption [VA]: max. 10 VA (contactor tripped)
max. 5 VA (downtime status)
Max. switching capacity [kW]:
P
2
≤ 4 kW, AC 3
Max. current [A]: 12 A
Motor protection:
Integrated thermal protection (thermal winding contact, WSK) in pump motor
Protection class:
54
Max. fuse protection on mains side [A]: 16 A, slow-blow
Ambient temperature [°C]:
–20 to +60 °C
Alarm contact:
Contact load max. 250V~, 1 A
Measurement range, internal sensor: 0-1 mWs (0-2 mWS option)
Hose connection for plastic hose:
Ø 8 mm x Ø 6 mm (exterior x interior)
Housing material:
ABS
Housing dimensions: 190 mm x 320 mm x 110 mm (WxHxD)
(dimensions incl. threaded cable connection and air connection)
Electrical safety:
Degree of contamination II
