2. Operation
1 only displayed when an MESplus control is present and this has been adjusted by
a trained service technician in the basic settings.
5s
RESET
Fig. 108
Boiler temperature
(Operating phases)
Lighting ON
42
°C
42
°C
42
°C
2.8.1.6 Time profile ash compression
The ash in the ash pan is only compressed at the 2 set start
times and when approx. 15 kg of fuel has been consumed.
The start times can be set in steps of 15 minutes (start time
1 and start time 2).
Factory setting: Start time 1: 08:00
Start time 2: 22:00
Pressing one of the six buttons switches the lighting and
display on – Fig. 108.
5s
RESET
Fig. 109
Boiler temperature
(Operating phases)
Info Menu
42
°C
42
°C
42
°C
5s
RESET
Fig. 110
Operator level
Service level
Information level
MES Module
1
Choose Back
5s
RESET
Fig. 111
Boiler cleaning
Time
Feed operating mode
Time profile feed
Probe switching
Time profile ash compression
Choose Back
Press the Menu button – Fig. 109.
Confirm the selected menu item „Operator level“ by pressing
the Choose button – Fig. 110.
Use the arrow buttons to select the sub-menu item „
Time
profile ash compression
“ markieren – Fig. 111.
