WinGD W-X82 - 9314-2;A1

Operation9314−2/A1
Winterthur Gas & Diesel Ltd.
2/ 3
WCH02857
I
I
II
21
I - I
II
3
3
5
FUEL SIDE
DRIVING END
2
3 34
4
WCH02857
10
113
Fig. 1: Location of Sensors
1 Cable guide 5 Column
2 Control unit E15.1 10 Control unit E15.2
3 Sensor 11 Terminal box E15.0
4 Fuel pump unit
2014-09
Oil Mist Detector 9-cylinders
