Operation
0850−1/A1
Winterthur Gas & Diesel Ltd.
7/ 39
4.4 Failure ID
ID Display Failure Text Failure Group
1 1 ME crank angle #1+2 fail. WECS critical
2 2 WECS critical failure WECS critical
3 3 WECS pressure failure WECS pressure
4 4 WECS cylinder failure WECS cylinder
5 5 WECS common failure WECS common
6 6 WECS passive failure WECS passive
8 8 ME scavenge air pressure sensor #1 meas. fail. WECS passive
8 8 ME scavenge air pressure sensor #2 meas. fail. WECS passive
9 9 ME scavenge air pressure sensor #1+2 meas. fail. WECS common
10 10 ME scavenge air pressure meas. fail. diff. high WECS common
11 11 ME Scavenge Air Pressure very HI (ID 11) WECS pressure
16 16 ME servo oil pressure sensor #1 meas. fail. WECS passive
16 16 ME servo oil pressure sensor #2 meas. fail. WECS passive
17 17 ME servo oil pressure sensor #1+#2 meas. fail. WECS common
18 18 ME servo oil pressure meas. fail. diff. high WECS common
19 19 ME servo oil pressure high WECS common
20 20 ME servo oil pressure low WECS common
21 21 ME servo oil pressure very low WECS pressure
26 26 ME servo oil pump #1 fail. WECS common
26 26 ME servo oil pump #2 fail. WECS common
27 27 ME fuel rail pressure sensor #1 meas. fail. WECS passive
27 27 ME fuel rail pressure sensor #2 meas. fail. WECS passive
28 28 ME fuel rail pressure sensor #1+#2 meas. fail. WECS common
29 29 ME fuel rail pressure meas. fail. diff. high WECS common
30 30 ME fuel rail pressure high WECS common
31 31 ME fuel rail pressure low WECS common
32 32 ME fuel rail pressure very low WECS pressure
33 33 WECS any FCM−20 cyl. ID lost WECS passive
38 38 WECS CAN M-bus fail. FCM−20 #nn WECS passive
39 39 WECS Modbus fail. FCM−20 #01 or #02 WECS passive
42 42 WECS CAN S-/ SSI-bus connection fail. FCM−20 #nn WECS passive
45 45 ME manual injection cutoff cylinder #nn WECS cylinder
60 60 ME crank angle difference between #1 and #2 WECS common
62 62 ME TDC signal fail. WECS common
63 63 ME crank angle #1 / TDC high shift WECS common
64 64 ME crank angle #2 / TDC high shift WECS common
65 65 ME both CA / TDC high shift WECS critical
2014
Failures and Defects of WECS Components
