WinGD W-X82 - 9314-1;A1

Operation9314−1/A1
Winterthur Gas & Diesel Ltd.
2/ 3
WCH01142
I
I
II
3
12
I - I
II
3
3
4
3
5
FUEL SIDE
DRIVING END
Fig. 1: Location of Sensors
1 Cable guide 4 Fuel pump unit
2 Control unit E15.1 5 Column
3 Sensor
2014-09
Oil Mist Detector 6-cylinders to 8-cylinders
