Operation
2138−1/A1
Winterthur Gas & Diesel Ltd.
1/ 2
Lubricating Quills on Cylinder Liner
1. General
Eight lubricating quills (1, Fig. 1) are are installed around the circumference of the
cylinder liner (2). The lubricating pump (3) supplies lubricating oil through pipes to
each lubricating quill (1).
2
1
3
WCH01128
Fig. 1: Location of Lubricating Quills
1 Lubricating quill 3 Lubricating pump
2 Cylinder liner
2014
