Startup and operation TPM
+
en-18 4022-D018396 Revision: 07
6 Startup and operation
6.1 Safety instructions and operating conditions
 Read the general safety instructions before beginning work (see Chapter 2.7 "General safety
instructions").
 Wearing hearing protection in the vicinity of the servo actuator is recommended.
6.2 Data for the electrical startup
The specified data is intended for the electrical startup.
 In some servo controllers, there is a dependence between the individual parameters. We would
be glad to assist you in finding the correct entries.
 We provide adjusted and certified quick start guides for several servo controllers. In these
guides you will find the adapted parameter lists for the relevant servo converters.
 For further information, please visit our website at http://wittenstein-alpha.de or contact our
Customer Service: service@wittenstein.de
This data reflects the technical characteristics and the limit values of the standard engines of the
TPM
+
- series in general units. Possible restrictions due to the gearhead can be found in the data
sheet of your servo actuator.
 Select the data for the TPM
+
- version you are using.
- Chapter 9.4.4 "Motor data, TPM
+
dynamic 320V, i = 16 – 31"
- Chapter 9.4.5 "Motor data, TPM
+
dynamic 320V, i = 61 – 91"
- Chapter 9.4.6 "Motor data, TPM
+
high torque 320V"
- Chapter 9.4.7 "Motor data, TPM
+
power 320V"
- Chapter 9.4.8 "Motor data, TPM
+
dynamic 560V, i = 16 – 31"
- Chapter 9.4.9 "Motor data, TPM
+
dynamic 560V, i = 61 – 91"
- Chapter 9.4.10 "Motor data, TPM
+
high torque 560V"
Improper use can cause damage to the servo actuator.
 Ensure that
- The ambient temperature does not drop below 0 °C or exceed
+40 °C,
- The surface temperature on the gearhead does not exceed +90°C,
- The surface temperature on the engine does not exceed +115°C,
- The installation altitude is not above 1000 m NHN.
 For other conditions of use, consult our Customer Service department.
 Use the sensor only up to its maximum limit values, see Chapter 9.4
"Technical specifications".
 Only use the servo actuator in a clean, dust-free and dry environment.
 Operate the servo actuator only in the mounting position that is specified
on the identification plate.
The servo controllers of the different manufacturers generally use an
individual annotation of the data.
If the data is disregarded, the drive and/or the servo controller may be
damaged.
 Observe the listed units precisely and check their conformance with the
units of the servo controller.
 If the units differ, make the necessary adjustment accordingly.
