9.4.10 Motor data, TPM
+
high torque 560V
Winding resistance at
20 °C terminal-terminal
Ohm 37.4 40 13.5 4 0.45
Winding inductance
terminal-terminal
mH 30 30 18.9 11.1 3
Electrical time constant
T
e
msec 0.8 0.8 1.4 2.8 6.7
Max. winding
temperature θ
max
°C 155 155 155 155 155
* Depending on the static and dynamic loads as well as the lambda factor, the continuous stall
current and the maximum current of the motor needs to be limited if necessary.
 You can determine the design for each case with our design software cymex
®
.
Tbl-25: Motor data, TPM
+
dynamic 560V, i = 61 – 91
General data
Unit TPM
+
010 TPM
+
025 TPM
+
050 TPM
+
110
Ratio i 22 –
110
154 –
220
22 –
55
66 –
220
22 –
55
66 –
220
22 –
55
66 –
88
110 –
220
Stator length mm 45 15 60 45 60 60 120 60 60
Pole pair number
p
p 666666666
Maximum torque
T
max
Nm 11.98 4.4 28.9 11.98 56.6 28.9 164.5 88 56.6
Maximum current
I
max
*
Aeff 17 6 40 17 63.5 40 160 100 63.5
Maximum speed rpm 4850 4850 4850 4850 4500 4850 4150 4150 4500
Continuous stall
torque T
0
Nm 3.75 1.44 10.92 4.19 19.28 11.11 63.6 40.35 22.18
Continuous stall
current I
0
*
Aeff 4.99 1.92 13.08 5.76 17.93 12.6 53.7 40.85 20.5
Torque constant
K
t
Nm/
Aeff
0.83 0.82 0.98 0.83 1.21 1.0 1.17 1.09 1.19
Voltage constant
K
e
Veff/
krpm
50.3 49.2 59.2 50.3 73.4 61.0 70.9 66.1 71.9
Winding
resistance at 20
°C terminal-
terminal
Ohm 2.36 15.7 0.47 2.36 0.29 0.47 0.05 0.08 0.29
General data
Unit TPM
+
004
TPM
+
010
TPM
+
025
TPM
+
050
TPM
+
110
