9.4.17 Technical specifications Heidenhain Incremental
9.4.18 Technical specifications TTL Encoder incremental
9.4.19 Technical specifications temperature sensors KTY and NTC
Incremental
Ordering code: TPMxxxxx-xxxI-xxxx-xxxx-xx-xxx
TPM
+
dynamic 004 –110
TPM
+
high torque 010 –110
TPM
+
power 004 –110
Type ERN 1185
Operating voltage 5 V
Number of SinCos periods per revolution 2048
Tbl-33: Technical specifications Heidenhain Incremental
TTL Encoder incremental
Ordering code: TPMxxxxx-xxxT-xxxx-xxxx-xx-xxx
TPM
+
dynamic 004 –110
TPM
+
high torque 010 –110
TPM
+
power 004 –110
Type Sick-Stegmann CKS36
Operating voltage 5 V
Commutation signals The motor polar pair number
appropriately programmed.
Increments per revolution 2048
Tbl-34: Technical specifications TTL Encoder incremental
Type KTY 84-130 NTC P1H104
Ordering
code:
TPMxxxxx-xxxx-xKxx-xxxx-xx-xxx TPMxxxxx-xxxx-xNxx-xxxx-xx-xxx
Temperature
[C]
Resistance, type [kohm] Resistance, type [kohm]
-30 0.391 1770
-20 0.424 971
-10 0.460 553
0 0.498 327
10 0.538 199
20 0.581 125
25 0.603 100
30 0.626 81
40 0.672 53
50 0.722 36
60 0.773 25
70 0.826 18
