Wittenstein TPM dynamic - 21 Technical Specifications Brake TPM + Dynamic

TPM
+
Appendix
Revision: 07 4022-D018396 en-41
9.4.21 Technical specifications brake TPM
+
dynamic
The listed opening and closing times are noted without the use of an additional wiring of the brake.
 To avoid interfering signals from the switching of the brake, in general an additional wiring, e.g.
in form of a varistor, should be added. Observe the requirements for this of the applied servo
controller manufacturer.
9.4.22 Technical specifications brake TPM
+
high torque
The listed opening and closing times are noted without the use of an additional wiring of the brake.
 To avoid interfering signals from the switching of the brake, in general an additional wiring, e.g.
in form of a varistor, should be added. Observe the requirements for this of the applied servo
controller manufacturer.
Ordering code: TPM xxxx-xxxx-xxBx-xxxx-xx-xxx
Unit TPM
+
004 TPM
+
010 TPM
+
025 TPM
+
050 TPM
+
110
Voltage V DC 24 24 24 24 24
Power
consumption
A DC 0.42 0.42 0.58 0.71 0.71
Holding torque at
120 C
Nm 1.1 1.1 4.5 13 13
Opening time msec 11 11 30 42 42
Closing time msec 10 10 20 20 20
Tbl-37: Technical specifications brake TPM
+
dynamic
Ordering code: TPMAxxxx-xxxx-xxBx-xxxx-xx-xxx
Unit TPM
+
010 TPM
+
025 TPM
+
050 TPM
+
110
Ratio i 22 –
110
154 –
220
22 –55 66 –
220
22 –55 66 –
220
22 –
88
110 –
220
Voltage V DC 24 24 24 24 24 24 24 24
Power
consumption
A DC 0.58 0.46 0.71 0.58 1.0 0.71 1.67 1.0
Holding
torque at 120
C
Nm 4.5 1.8 13 4.5 23 13 72 23
Opening time msec 30 30 42 30 50 42 200 50
Closing time msec 20 25 20 20 40 20 50 40
Tbl-38: Technical specifications brake TPM
+
high torque
