Wittenstein TPM dynamic - Motor Data, TPM + Dynamic 560 V, I = 16 - 31

TPM
+
Appendix
Revision: 07 4022-D018396 en-33
9.4.8 Motor data, TPM
+
dynamic 560V, i = 16 – 31
9.4.9 Motor data, TPM
+
dynamic 560V, i = 61 – 91
General data
Unit TPM
+
004
TPM
+
010
TPM
+
025
TPM
+
050
TPM
+
110
Stator length mm 30 30 45 60 75
Pole pair number p p 44666
Maximum torque T
max
Nm 2 3.8 12.1 28.9 43.9
Maximum current I
max
* Aeff 3.2 5.2 17 40 70
Maximum speed rpm 6000 6000 6000 5000 5000
Continuous stall torque
T
0
Nm 0.72 1.2 5.5 13.49 16.42
Continuous stall
current I
0
*
Aeff 1.1 1.3 5.7 13.7 16.7
Torque constant K
t
Nm/Aeff 0.7 0.97 0.98 1 1
Voltage constant K
e
Veff/krpm 42.2 58.5 59.5 61 61
Winding resistance at
20 °C terminal-terminal
Ohm 28.2 21.3 2.2 0.45 0.32
Winding inductance
terminal-terminal
mH 33.3 22.8 6 3 2.4
Electrical time constant
T
e
msec 1.2 1.1 2.7 6.7 7.4
Max. winding
temperature θ
max
°C 155 155 155 155 155
* Depending on the static and dynamic loads as well as the lambda factor, the continuous stall
current and the maximum current of the motor needs to be limited if necessary.
 You can determine the design for each case with our design software cymex
®
.
Tbl-24: Motor data, TPM
+
dynamic 560V, i = 16 – 31
General data
Unit TPM
+
004
TPM
+
010
TPM
+
025
TPM
+
050
TPM
+
110
Stator length mm 15 15 15 15 60
Pole pair number p p 44666
Maximum torque T
max
Nm 0.98 1.9 4.4 7.8 28.9
Maximum current I
max
* Aeff 2.4 3 6 12 40
Maximum speed rpm 6000 6000 6000 5000 5000
Continuous stall torque
T
0
Nm 0.36 0.67 1.86 3.59 13.49
Continuous stall
current I
0
*
Aeff 0.8 0.9 1.9 3.8 13.7
Torque constant K
t
Nm/Aeff 0.47 0.78 1.02 0.97 1
Voltage constant K
e
Veff/krpm 28.3 47.4 61.3 58.7 61
