Wittenstein TPM dynamic - 13 Technical Specifications, Resolver

TPM
+
Appendix
Revision: 07 4022-D018396 en-37
9.4.14 Technical specifications Stegmann Hiperface absolute encoder
9.4.15 Technical specifications Stegmann Hiperface absolute encoder, Rockwell option
Impedance ZR0 140 ohm 70 + j 100 ohm
Impedance ZS0 – 180 + j 300 ohm
Impedance ZSS 120 ohm 175 + j 257 ohm
Max. operating temperature 155 °C 155 °C
Tbl-29: Technical specifications, Resolver
Singleturn
Ordering code: TPMxxxxx-xxxN-xxxx-xxxx-xx-xxx
TPM
+
dynamic 004 –110
TPM
+
high torque 010 –110
TPM
+
power 004 –110
Type SKS36
Operating voltage 7-12 V
Protocol Hiperface
Number of SinCos periods per revolution 128
Multiturn
Ordering code: TPMxxxxx-xxxK-xxxx-xxxx-xx-xxx
TPM
+
dynamic 004 –110
TPM
+
high torque 010 –110
TPM
+
power 004 –110
Type SKM36
Operating voltage 7-12 V
Protocol Hiperface
Number of SinCos periods per revolution 128
Number of Multiturn revolutions 4096
Tbl-30: Technical specifications Stegmann Hiperface
Singleturn
Ordering code: TPM xxxx-xxxE-xxxx-xxxx-x5-xxx
TPM
+
dynamic 560V U
DCBus
TPM
+
dynamic 320V U
DCBus
Type SKS36 SKS36
Operating voltage 7-12 V 5 V
Protocol Hiperface Hiperface
Number of SinCos
periods per revolution
128 128
Ordering code: TPMxxxxx-xxxR-xxxx-xxxx-xx-xxx
TPM
+
dynamic 004 TPM
+
dynamic 010 – 110
TPM
+
high torque 010 – 110
TPM
+
power 004 – 110
