Appendix TPM
+
en-40 4022-D018396 Revision: 07
9.4.20 Technical specifications temperature sensor PTC
80 0.882 13
90 0.940 9.2
100 1.000 6.8
110 1.062 5.2
120 1.127 3.9
130 1.194 3
140 1.262 2.4
150 1.334 1.9
160 1.407 1.5
170 1.482 1.2
180 1.560 1
190 1.640 0.8
200 1.722 0.7
Tbl-35: Technical specifications temperature sensors KTY and NTC
PTC STM 160
Ordering code: TPMxxxxx-xxxx-xPxx-xxxx-xx-xxx
Deactivation in case of fault
Characteristic line in accordance with DIN 44081/44082
Temperature [C] Resistance [ohm]
< 140 20 - 250
140 - 155 250 - 550
155 - 165 550 - 1330
165 - 175 1330 - 4000
> 175 > 4000
Tbl-36: Technical specifications temperature sensor PTC
Type KTY 84-130 NTC P1H104
Ordering
code:
TPMxxxxx-xxxx-xKxx-xxxx-xx-xxx TPMxxxxx-xxxx-xNxx-xxxx-xx-xxx
Temperature
[C]
Resistance, type [kohm] Resistance, type [kohm]
