Revision: 07 4022-D018396 en-35
9.4.11 Motor data, TPM
+
power 560V, i = 4 – 35
Winding
inductance
terminal-terminal
mH 6 18.9 3 6 2.1 3 0.67 0.9 2.1
Electrical time
constant T
e
msec 2.5 1.2 6.4 2.5 7.3 6.4 14 10.8 7.2
Max. winding
temperature θ
max
°C 155 155 155 155 155 155 155 155 155
* Depending on the static and dynamic loads as well as the lambda factor, the continuous stall
current and the maximum current of the motor needs to be limited if necessary.
 You can determine the design for each case with our design software cymex
®
.
Tbl-26: Motor data, TPM
+
high torque 560V
General data
Unit TPM
+
004
TPM
+
010
TPM
+
025
TPM
+
050
TPM
+
110
Stator length mm 30 45 60 60 60
Pole pair number p p 46666
Maximum torque T
max
Nm 3.8 12.1 28.9 56.6 88
Maximum current I
max
* Aeff 5.2 17 40 63.5 100
Maximum speed rpm 6000 6000 6000 5000 4200
Continuous stall torque
T
0
Nm 1.25 4.5 11.68 19.3 36.9
Continuous stall
current I
0
*
Aeff 1.56 5.4 13.7 19 38.6
Torque constant K
t
Nm/Aeff 0.97 0.98 1 1.19 1.09
Voltage constant K
e
Veff/krpm 58.5 59.5 61 71.9 66.1
Winding resistance at
20 °C terminal-terminal
Ohm 21.3 2.2 0.45 0.27 0.08
Winding inductance
terminal-terminal
mH 22.8 6 3 2.1 0.9
Electrical time constant
T
e
msec 1.1 2.7 6.7 8 11.2
Max. winding
temperature θ
max
°C 155 155 155 155 155
* Depending on the static and dynamic loads as well as the lambda factor, the continuous stall
current and the maximum current of the motor needs to be limited if necessary.
 You can determine the design for each case with our design software cymex
®
.
Tbl-27: Motor data, TPM
+
power 560V, i = 4 – 35
General data
Unit TPM
+
010 TPM
+
025 TPM
+
050 TPM
+
110
Ratio i 22 –
110
154 –
220
22 –
55
66 –
220
22 –
55
66 –
220
22 –
55
66 –
88
110 –
220
