9 Appendix
In case of questions on the special applications, please contact WITTENSTEIN alpha GmbH.
9.1 Specifications on mounting onto a machine
9.1.1 Specifications for the TPM
+
dynamic/TPM
+
power version
9.1.2 Specifications for the TPM
+
high torque version
9.2 Specifications on mounting on the gear output side
9.2.1 Thread in output flange, TPM
+
dynamic
Through-holes in the servo actuator housing TPM
+
dynamic/TPM
+
power
Type/Size Bore Ø
[mm]
Quantity x
diameter
[ ] x [mm]
For screw size /
property class
Tightening torque
[Nm]
TPM
+
004 79 8 x 4.5 M4 / 12.9 4.55
TPM
+
010 109 8 x 5.5 M5 / 12.9 9.0
TPM
+
025 135 8 x 5.5 M5 / 12.9 9.0
TPM
+
050 168 12 x 6.6 M6 / 12.9 15.4
TPM
+
110 233 12 x 9.0 M8 / 12.9 37.3
Tbl-11: Specifications on mounting onto a machine, TPM
+
dynamic / TPM
+
power
Through-holes in the servo actuator housing TPM
+
high torque
Type/Size Holecircle Ø
[mm]
Quantity x
diameter
[ ] x [mm]
For screw size /
property class
Tightening torque
[Nm]
TPM
+
010 109 16 x 5.5 M5 / 12.9 9.0
TPM
+
025 135 16 x 5.5 M5 / 12.9 9.0
TPM
+
050 168 24 x 6.6 M6 / 12.9 15.4
TPM
+
110 233 24 x 9.0 M8 / 12.9 37.3
Tbl-12: Specifications on mounting onto a machine, TPM
+
high torque
Type/Size Indexbore Øx
depth
[mm] x [mm]
Bore Ø
[mm]
Quantity x Thread
x Depth
[ ] x [mm] x [mm]
Tightening torque
[Nm]
Property class
12.9
TPM
+
004 5 H 7 x 8 31.5 7 x M5 x 7 9.0
TPM
+
010 6 H 7 x 7 50.0 7 x M6 x 10 15.4
TPM
+
025 6 H 7 x 7 63.0 11 x M6 x 12 15.4
TPM
+
050 8 H 7 x 10 80.0 11 x M8 x 15 37.3
TPM
+
110 10 H 7 x 12 125.0 11 x M10 x 20 73.4
Tbl-13: Thread in output flange (ISO9409), TPM
+
dynamic
