TPM
+
Appendix
Revision: 07 4022-D018396 en-27
9.2.2 Thread in output flange, TPM
+
high torque
9.2.3 Thread in output flange, TPM
+
power
9.3 Tightening torques for common thread sizes in general mechanical engineering
The specified tightening torques for headless screws and nuts are calculated values and are based
on the following conditions:
- Calculation in accordance with VDI 2230 (February 2003 version)
- Friction value for thread and contact surfaces µ=0.10
- Exploitation of the yield stress 90%
- Torque tools type II classes A and D in accordance with ISO 6789
The settings are values rounded to usual commercial scale gradations or setting possibilities.
 Set these values precisely on the scale.
Type/Size Bore Ø
[mm]
Quantity x Thread x Depth
[ ] x [mm] x [mm]
Tightening torque
[Nm]
Property class 12.9
TPM
+
010 50.0 12 x M6 x 10 15.4
TPM
+
025 63.0 12 x M8 x 12 37.3
TPM
+
050 80.0 12 x M10 x 15 73.4
TPM
+
110 125.0 12 x M12 x 19 126.0
Tbl-14: Thread in output flange (ISO9409), TPM
+
high torque
Type/Size Bore Ø
[mm]
Quantity x Thread x Depth
[ ] x [mm] x [mm]
Tightening torque
[Nm]
Property class 12.9
TPM
+
004 31.5 8 x M5 x 7 9.0
TPM
+
010 50.0 8 x M6 x 10 15.4
TPM
+
025 63.0 12 x M6 x 12 15.4
TPM
+
050 80.0 12 x M8 x 15 37.3
TPM
+
110 125.0 12 x M10 x 20 73.4
Tbl-15: Thread in output flange (ISO9409), TPM
+
power
Tightening torque [Nm] with thread
Property
class
Screw / nut
M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
8.8 / 8 1.15 2.64 5.2 9.0 21.5 42.5 73.5 118 180 258 362 495 625
10.9 / 10 1.68 3.88 7.6 13.2 32.0 62.5 108 173 264 368 520 700 890
12.9 / 12 1.97 4.55 9.0 15.4 37.5 73.5 126 202 310 430 605 820 1040
Tbl-16: Tightening torques for headless screws and nuts
