9.4.28 Cable setup / Cable cross-section
For ambient temperatures up to +30 C, the following applies for cables acc. to DIN EN 60204:
Continuous stall
current
Cable
0 –15 Aeff 4 x 1.5 mm
2
& 2 x 0.75 mm
2
15 –21 Aeff 4 x 2.5 mm
2
& 2 x 1 mm
2
21 –36 Aeff 4 x 6 mm
2
& 2 x 1.5 mm
2
36 –50 Aeff 4 x 10 mm
2
& 2 x 1.5 mm
2
50 –66 Aeff 4 x 16 mm
2
& 2 x 1.5 mm
2
Tbl-42: Cable setup / Cable cross-section
