2-14
Installation InformationCT Hoods and DD Ventilation
LOW-PROFILE WALL HOODS INSTALLATION SPECIFICATIONS AND PREPARATIONS
NOTE: This installation must be completed by a qualifi ed installer or Wolf authorized service center technician.
NOTE: Low Profi le Hoods are designed for use with a 6” diameter duct.
CTE W
ALL HOOD DUCTED INSTALLATION
Locate the electrical supply through the wall within the shaded area shown in Figure 23.1.
Install ductwork as outlined on page 2-13 & Figure 2-22.2.
If an optional backsplash is to be used, attach it to the fi nished wall. Secure the hood mounting brackets to the 3.
wall studs prior to installing the backsplash.
DUCT WORK
INSTALLATION
THROUGH
ROOF
DUCT WORK
INSTALLATION
THROUGH
WALL
24" (610)
TO
30" (762)
COUNTERTOP
TO B OTTOM
OF HOOD
TO
HEIGHT
OF HOOD
17
3
/4"
(451)
DEPTH OF HOOD
29
1
/8” (740)
41
1
/2” (1054)
Figure 2-22 CTE Wall Hood Installation Considerations
