Wolf CT - Supply Voltage Requirements

6-2
Technical DataCT Hoods and DD Ventilation
TO AVOID ELECTRIC SHOCK, POWER TO A VENTILATION UNIT MUST BE DISCONNECTED WHENEVER
ACCESSING AND/OR REMOVING COMPONENTS POWERED BY ELECTRICITY OR COMPONENTS NEAR
OTHER ELECTRICAL COMPONENTS.
Model CTWH ................ 120 VAC / 60 Hz. / 15 amp
Model IH ....................... 120 VAC / 60 Hz. / 15 amp
Model DD ..................... 120 VAC / 60 Hz. / 15 amp
Model ICBDD ............... 240 VAC 50/60Hz. / 10 amp
Model CTEW & CTEI ... 120 VAC/ 60Hz. / 15 amp
Metal edges may be sharp. Use caution when servicing unit to avoid personal injury.
Supply Voltage Requirements
Speed Control: Low: 68+/-5 VAC-RMS
Medium: 80+/-5 VAC-RMS
High: 116 VAC-RMS, Minimum
Lighting Transformer Primary Secondary
Low ............ 30 VAC 3 VAC
Medium ..... 60 VAC 6 VAC
High ........... 120 VAC 12 VAC
DD 500 Cfm Internal Blower Rating: 4.0 amps
Component Output Levels Domestic CT Hoods & Downdraft
Heat Sentry Activation Temperature:
Closes 206°F (97°C)
Opens - 174°F (79°C )
Temperature Parameters
Speed Output Levels ICBDD
Speed Control (50Hz): Low: 97+/-10 VAC
Medium: 121+/-10 VAC
High: 230 VAC, Minimum
Speed Control (60Hz): Low: 137+/-10 VAC
Medium: 158+/-10 VAC
High: 230 VAC, Minimum
CTE Low Profi le Hoods Fuse Specifi cations
Function Location Rating
12V Control ..... Control Board .............. 250V 4amp
Lighting ............ Harness Fuse Holders . 250V 630mA
