Wolf CT - Component Output Levels CTE Low Profile Hoods

6-3
Technical Data CT Hoods and DD Ventilation
Component Output Levels CTE Low Profi le Hoods
Component
(command level)
Control
Board
Test Point
Wire Color
(if applicable)
Expected
Voltage Reading
@ 120V/60Hz
Expected
Amperage Reading
@ 120V/60Hz
Transformer
Primary
(stand-by) CN6 n/a 120V 0.29A
Transformer
Secondary
(stand-by) CN5 n/a 13.08V 0.03A
Input Power
(stand-by) CN7 n/a 120V 0.29A
Halogen Lamp
(1/2 light) CN3 n/a 6.25V 2.18A
Halogen Lamp
(max light) CN3 n/a 11.44V 11.44A
Halogen Lamp
(1/2 light) CN2 n/a 6.25V 2.18A
Halogen Lamp
(max light) CN2 n/a 11.44V 11.44A
Blower Output
(speed 4) CN1 Red/Black 120V 2.78A
Blower Output
(speed 3) CN1 Red/Orange 120V 2.72A
Blower Output
(speed 2) CN1 Red/White 120V 2.26A
Blower Output
(speed 1) CN1 Red/Blue 120V 1.88A
Speed Output Levels CTE Low Profi le Hoods
Speed Control: Level 1: 63 +/-3 VAC
Level 2: 69 +/-3 VAC
Level 3: 78 +/-3 VAC
Level 4: 114 +/-3 VAC
NOTE: Measured at Power Board (Printed Circuit Board) motor connector
