Troubleshooting Guide
Circuit Breaker Operation
Troubleshooting Guide 60HDdoc081208 6-19
6
6.11 Circuit Breaker Operation
Sawmill controls are equipped with manual reset circuit breakers to protect the electrical
circuits.
See Figure 6-5. The power feed and up/down breakers are externally mounted at the
front of the control box. The blade guide, accessory, ignition, start, and board return
breakers are located inside the control box. Remove the circuit breaker panel from the
control box to access the internal breakers.
NOTE: If the breaker is still hot, you may not be able to
reset it immediately. Allow the breaker to cool for a few min-
utes before attempting to reset.
