Specifications
Log Capacity
8
8-1 60doc081208 Specifications
SECTION 8 SPECIFICATIONS
8.1 Log Capacity
See Table 8-1. The LT70 Series Sawmills can accept logs as listed below.
8.2 Overall Dimensions
See Table 8-1. The overall dimensions of the LT70L are listed below.
LT70S LT70M LT70L
Maximum Log Diameter 36,6” ( 93 cm ) 36,6” ( 93 cm ) 36,6” ( 93 cm )
Maximum Log Length
1
1
Added length capacity provided with bed extension options. Add length of bed extension to
sawmill length capacity (ie. BX12, add 12’).
15’-11” (4.9 m ) 20’-2” ( 6.1 m ) 27’-6” ( 8.4 m )
Maximum Log Weight
2
2
Sawmills equipped with bed extensions can accept heavier logs if the weight is distributed so
neither the sawmill or extension is loaded beyond the 4400 lbs. (1996 Kg) limit. Loading logs
heavier than 4400 lbs. (1996 Kg) on a sawmill equipped with a bed extension requires auxil-
iary log handling equipment.
4400 lbs. ( 1996 kg) 4400 lbs. (1996 kg) 6614 lbs. (3000 kg)
TABLE 8-1
LT70L
Length 10,8 m
Width 2,3 m
Height 2,3 m
Weight
1
1
Weight with optional trailer and heaviest engine
option.
2780 kg.
TABLE 8-1
