Sawmill Setup
Portable Sawmill Setup
3
3-5 60HDdoc081208 Sawmill Setup
3.3 Portable Sawmill Setup
WARNING! Do not set up the mill on ground with more than
a 10 degree incline. If setup on an incline is necessary, put
blocks under one side of the mill or dig out areas for outrig-
ger legs to keep mill level. Setting up the mill on an incline
could cause it to tip over, resulting in serious personal
injury.
WARNING! Chock the trailer wheels to prevent movement
before unhitching it from the towing vehicle. Failure to do so
may result in serious injury or death.
WARNING! Always make sure the trailer is supporting the
sawmill frame when operating a sawmill with adjustable
outriggers. Failure to do so may result in serious injury or
death. The adjustable outriggers are intended to support
the saw frame with assistance from the trailer.
1. Unhitch the mill from the vehicle.
2. Lower and set the front outriggers. To lower the leg, pull the locking pin out of the outrig-
ger hole. When the outrigger contacts the ground, release the pin. Place a 19 socket
wrench on the outrigger adjustment bolt and turn the bolt until the locking pin enters the
nearest outrigger hole.
WARNING! Put front outrigger down before moving cutting
head from the rest position. Failure to do so may result in
serious injury.
