Sawmill Alignment
Complete Alignment Procedure
7
7-17 60HDdoc081208 Sawmill Alignment
7.4 Complete Alignment Procedure
Frame Setup
Before performing the following alignment procedures, setup the mill on firm, level
ground.
If your sawmill is stationary, with no trailer axle, lower the feet so the weight of the sawmill
is evenly supported.
If your sawmill has a trailer axle and adjustable outriggers, adjust the outriggers as fol-
lows:
LT70S: Adjust the two end outriggers on the main frame tube down just enough to lift
weight from the trailer tire.
LT70M: Adjust the front and third outriggers on the main frame tube down just enough to
lift weight from the trailer tire.
LT70L. Adjust front outriggers on the main frame tube down just enough to lift weight from
the trailer tires.
All Portable Sawmills: Adjust the outer outriggers down just so they touch the ground
but do not bear weight.
See SECTION 3
for additional setup information.
