Hydraulic Blade Tensioner Components
Specifications 60doc081208 8-6
8
8.8 Hydraulic Blade Tensioner Components
8.9 Sawdust Extractor Specifications
See Table 8-9. The dust extractor specifications are given below.
ID Description
1 Non-return Valve HVR NW10MLED
2 Hose DN-12
3 Hose DN-12
4 T-Pipe DT RNW10HL
5 Connector VRNW10HL
6 Elbow W90HROKO6HJ04
7 Hose 1/4”
8 Elbow W90HROK04HJ
9 Valve ECP 20/22B2
10 Connector 4-4F642E DM XS
11 Throttle Valve VSG522.100000
12 Connector 4-4F42ED MXS
TABLE 8-8
Maximum Capacity
1200 m
3
/h
Collector Inlet Diameters
(in front of fan)
150 MM.
Motor Power 1.5 kwh
Number of Sacks for Waste 1 pcs
Total Capacity of Sacks
0,25 m
3
Weight 110 kg
Conveying Speed When 10 m
Long Hose Is Used
20 m/s
