Safety
Safety Instructions
1
1-13
60HD
doc081208
Safety
099221
CAUTION! Keep all perso
ns a safe
distance away from work area when
operating the mach
ine.
098176
CAUTION! Keep away from debarker
blade!
096316
CAUTION! Do not open or close the
electric box when the switch
is no
t
in the
“0” position.
TABLE 1-1
099221
098176
17
19
