Sawmill Operation
Loading, Turning And Clamping Logs
Sawmill Operation 60HDdoc081208 4-4
4
If you want to turn the log more, do the following steps.
3. Engage the clamp by raising the clamp in/out lever. Clamp the log against the side sup-
ports.
4. Lower the turner lever to lower the turner arm below the log.
5. Raise the turner arm to get a new bite on the log.
6. Disengage the clamp.
The log can be turned now. Repeat steps 4 through 7 until the log is turned as desired.
Turning small cants
If you are turning a small cant, use the middle log clamp to turn the cant, instead of the
log turner.
1. Lower the clamp up/down lever to lower the clamp below bed level.
2. Use the clamp in/out lever to move the clamp in, beneath the edge of the cant.
3. Raise the clamp up/down lever to raise the clamp and flip the cant.
To Use The Middle Clamp
1. Raise the clamp up/down lever to raise the clamp.
2. Use the clamp in/out lever to clamp the log against the side supports.
3. Lower the turner lever until the turner arm falls below the bed.
4. Using the clamp in/out lever, back the clamp off slightly.
5. Lower the side supports so that they are positioned below the level of your first few cuts.
6. Using the clamp in/out lever, clamp the log firmly.
Depending on the length of the log being sawn, you can use either the middle log clamp
together with the front clamp and the rear one (when the log length is minimum 3.5 m),
or the middle clamp together with the front clamp or the rear clamp (log length below 3.5
