Woods 208-2 - Page 45

Parts 43
32394 (Rev. 9/3/2004)
REF PART QTY DESCRIPTION
1 32399 2 Gearbox 1:1.35
2 15194 2 1-1/4 SQ ID x 2-3/8 Washer
3 32363 1 Input gearbox 1:1.35
4 28273 2 Torsion bar
5 28270 1 Gearbox shield
6 27270 1 Clutch shield
7 3444 2 Access hole cover assembly
8 32376 2 Side skid
9 NSS 1 Frame skipping unit
10 29269 2 1-5/8 Clamp crossbar assembly
(includes 45)
11 10520 4 18 GA 1-1/2 Blade pin shim
12 32603 4 Keyhole plate, special
13 32604 4 Blade pin lock clip, special
14 5523 4 Spacer
15 13946 1 20 GA 1-1/2 Blade pin shim
16 11768 2 CW Formed blade 20” (right spindle)
-or-
16 11769 2 CCW Formed blade 20” (left spindle)
-or-
16 11886 4 Double edge blade (L&R spindles)
17 32602 4 1-1/2 Blade pin, special
18 28315 1 Complete English decal set
19 20280 1 English safety decal set
20 50280 1 French safety decal set
21 32377 2 Torsion bar clamp
22 15831 2 Anti-wrap washer, 3.68 dia
HARDWARE
25 11204 13/16 x .010 Shim washer
26 11036 3/4 x 1-1/2 x 18 GA Shim washer
27 11041 * 3/8 x 3/8 x 2-7/8 Key
28 1287 * 3/8 NC Wing nut
29 6778 * 5/16 NC Hex locknut
30 10509 * 5/16 NC x 2-1/2 HHCS GR5
31 839 * 3/8 NC x 1 HHCS GR5
32 24722 3/8 x 1-5/8 x 10 GA Flat washer
33 3699 * 1/2 NC x 2 HHCS GR5
34 11900 * 1/2 NC Flanged hex locknut
35 6100 * 1/2 NC x 1-1/4 HHCS GR5
36 230 * 5/8 NC Hex nut
37 1286 * 5/8 Heavy lockwasher
38 5607 * 5/8 NC x 1-1/2 Carriage bolt
39 692 * 5/8 Standard flat washer
40 6239 * 5/8 NC Hex locknut
41 23638 5/8 NC x 7 HHCS GR5
42 7828 3/4 x 2-1/2 x 1/4 Flat washer, heat
treated
43 4616 3/4 NC x 1-1/2 HHCS HT
44 5791 1-1/8 Washer with hex hole
45 29272 1-5/8 x 2-1/4 x 7 GA Flat washer
46 7142 1/4 x 1/4 x 2 Key heat-treated
47 12400 .38 x 1.0 Sheet metal screw
48 11043 5/8 x 7-1/2 HHCS GR5
49 3231 * 3/8 NC x 2 HHCS GR5
50 14350 3/8 NC Flanged hex locknut
51 19080 .81 x 1.57 x .07 Washer
* Obtain Locally
NSS Not Sold Separately
REF PART QTY DESCRIPTION
