ENGINE
STW34, STW37, STW40, WSM
1-S10
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to See "5. TIGHTENING TORQUES" on page G-10.)
Item N·m kgf·m lbf·ft
Steering wheel mounting nut 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Delivery hose R.H. retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Delivery hose L.H. retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Delivery hose retaining nut 34.3 to 44.1 3.5 to 4.5 25.3 to 32.5
Delivery hose joint screw 45.1 to 53.0 4.60 to 5.40 33.3 to 39.0
Bi-speed delivery pipe joint screw 30 to 40 3.1 to 4.0 23 to 29
Bi-speed delivery pipe retaining nut 29 to 49 3.0 to 5.0 21.7 to 36.2
Engine mounting screw and nut (M10) 48.1 to 55.9 4.9 to 5.7 35.5 to 41.2
Engine mounting nut (M12) 77.5 to 90.2 7.9 to 9.2 57.2 to 66.5
Front axle frame mounting screw (M12) 78 to 90 7.9 to 9.2 58 to 66
Clutch mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.2
Muffler mounting screw 32 to 37 3.2 to 3.8 24 to 27
Rear wheel mounting screw and nut 196.1 to 225.6 20.0 to 23.0 145 to 166
Hydraulic hose PB, P and T retaining nut 30 to 40 3.1 to 4.0 23 to 29
Outer roof mounting screw 3.5 to 4.0 0.36 to 0.40 2.6 to 2.9
Cabin mounting bolt and nut 124 to 147 12.6 to15.0 91.1 to 108
