Page 5-28 Publication No. 150-041118
Section 5 – Configuration and Programming Rev. A
Sep 2001
PROG: 2=NEXT 3=BACK
ADD-..1
• Use the cursor/value knobs to select the number for the new channel. Only available channel numbers will be
displayed. Press the MODE button to go to the next menu page.
PROG: 2=NEXT 3=BACK
R/TSYS#=1
• Use the cursor/value knobs to select the radio this channel is being programmed for. Press the MODE button to
go to the next menu page.
• If both radios are RT-5000’s with the same part number, both radios will be able to use any channel. In this
case, set this value to “1”.
PROG: 2=NEXT 3=BACK
CHAN ID=............
• Use the cursor/value knobs to input the alphanumeric identifier for the channel being programmed. This
identifier can be a maximum of 12 characters in length. Turning the VALUE knob will enumerate all the
characters available for the identifier. Press the MODE button to go to the next menu page.
PROG: 2=NEXT 3=BACK
CHANNEL TYPE= FM
• Use the cursor/value knobs to input the modulation type for the channel being programmed. This can be AM,
FM, P (P25), or TK (trunking). Press the MODE button to go to the next menu page.
PROG: 2=NEXT 3=BACK
ZONE= .. CHANNEL= ..
• Use the cursor/value knobs to input the zone and channel number for a RT-5000 digital transceiver channel.
Leave these fields blank if you are not programming a digital transceiver channel. Press the MODE button to
go to the next menu page.
